Galvanized Roofing Sheet Machine Double Layers Forming Machine



galvanized roofing sheet machine,double layers forming machine



Our machine has passed CE and ISO certificated





1 This roll forming machine can roll forming metal panel which is mostly used with colorful roofing tile sheets. After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface.

2 we also can do a custom roll forming machine, We can design the machine according to your specification and profile drawing.

3 One roll forming machine only can produce one profile. The following profile drawing are some examples for your reference.





A profile with size







PS: the size is changable, please show us your desied size and then we design new machine specially for you



Wave height	10mm
Wave length	100mm
Cover width	1000mm
Coil width	1000mm
Thickness of material plate	0.3-0.8mm



 B parameters of  roof metal tiles machine



No.	main parameter of metal roofing rolling forming machine
1	Suitable to process	Color steel plate
2	Width of the plate	1250 and 1000mm
3	Rollers	13 rows
4	Dimensions	8000mm*1550mm*1510mm
5	Power	5.5+4kw
6	Thickness of the plate	0.3-0.8mm
7	Productivity	20-30m/min
8	Diameter of the roller	Φ70mm
9	Weight	About 2.5T
10	Voltage	380V 50Hz 3phases
11	Material of the cutting plate	Cr12
12	Hydraulic	40#
13	Processing precision	Within 1.00mm
14	Control system	Panasonnic PLC control





C flow chart of  roof metal tiles machine





D machine components

1. decoiler(optional)



upgrade manual decoiler or 5 ton auto decoiler with car











2. Feeding device





3.hydraulic system





4 plc control box



5. forming rollers and transmission









6. whole machine







7. set off table (optional)



 8. panel usage sample











9. rollformer loading







How to order:

we are good at custom made machines, kindly please send us your drawing or panel sample.
