High Speed Cold Steel Door Frame Bending Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Condition: | New | Machine Type: | Roll Forming Machine |
|---|---|---|---|
| Raw Material: | Sheet / Plate Rolling | Material / Metal Processed: | Steel |
| Power: | Hydraulic | Automation: | Automatic |
| Extra Services: | Bending | Weight (KG): | 900 |
| Key Selling Points: | Long Service Life | Warranty: | 1 Year |
| Applicable Industries: | Hotels, Building Material Shops, Restaurant, Home Use, Food Shop | Showroom Location: | None |
| After-sales Service Provided: | Free Spare Parts, Online Support, Video Technical Support, Engineers Available To Service Machinery Overseas | After Warranty Service: | Video Technical Support, Online Support, Spare Parts |
| Local Service Location: | None | Name: | High Speed Cold Steel Door Frame Bending Machine |
| Raw Material: | PPGI PPGL GI GL | Application: | Used For Metal Plate Bending |
| Thickness To Process: | 0.3-0.8mm Or Customized | Mould Material: | T8 |
| Oil Cylinder: | 4 Pcs | Oil Cylinder Diameter: | 120mm |
| Control System: | PLC | Voltage: | 380V/50HZ/3phase |
| Port: | Tianjin |
High speed cold steel door frame bending machine
Specification
|
Types of bending machine |
6 meters bending machie |
4 meters bending machine |
|
Sample |
|
|
|
Machine rough size (Length * Width * height ) |
6500mm*1000mm*2100mm |
4500*1000*2000mm |
|
Bending thickness |
Less than 4mm |
Less than 4mm |
|
Main motor |
4KW |
4KW |
|
Oil cylinder |
4pcs |
4pcs |
|
Oil cylinder diameter |
120mm |
120mm |
|
Mould material |
T8 |
T8 |
|
Machine rough weight |
2-3tons |
2-3tons |
PRODUCT DESCRIPTION
Welded structure and frame: forging press gives high accuracy. - High accuracy, high efficiency, simple and convenient operation, good performance.
Hydraulic system: - Adopt integrated hydraulic control system, more reliable - Consist of motor, oil pump and valve groups - Be installed at the top of the oil box, which can assure that the cylinder is always full .
WHY CHOOSE US
Decoiler---Main Roll forming system---Electric controlling system---Automatic cutting---Receiving table
Our Services
Packaging & Shipping
Company Information
Our company is a manufacturer with strong technologies for cold-forming equipment and its whole automatic production line . Our products are mainly used for IBR ,corrugated , glazed tile roll forming machines ,as well as the C Z purlin machine , light keel steel machine,shutter door machine,floor decking machine etc . On the strength of our strong technologies and manufacturing experience, we always place the customers'interests first and know that our sucess lies on the customer's success and development. From design to after-service, this principle is observed. By using our products,customers may improve efficiency , reduce costs and enhance competitive power .
FAQ
1. Q: What is the MOQ?
A: 1 set.
2. Q: What is the Delivery time?
A: Within 35 workdays.
3. Q: What is the Payment terms you can accept?
A: T/T or L/C.30% deposit,and before shipped we hope to receive the balance 70%.Also 100% L/C is accepted.
4. Q: What is the Warranty?
A: Within 1 years warranty .,All of the technical personnel are ready to serve you at any time.
5. Q:Can you make the machine according to my design or photo type?
A: Yes. We have an experienced team for working out the most suitable design and production plan for the machine that you are going to book with us
6. Q: How can we be assured that you will deliver us quality machine with spare parts?
A:1. Customers to send the technical people to our factory for checking the quality.
2.We can send the technicians to the buyer`s factory for the installation of the machine.
3.Good after-sales service, its free of charge during the warranty period.
